6 DOF Swing Test Table For Provide Position / Sine Wave Analog With 200kg Payload

6 DOF Swing Test Table For Provide Position / Sine Wave Analog With 200kg Payload

6 DOF Swing Test Table For Provide Position / Sine Wave Analog With 200kg Payload

Product Details:

Place of Origin: Wuhan, China
Brand Name: HEOS
Model Number: YBT6-200

Payment & Shipping Terms:

Minimum Order Quantity: 1
Delivery Time: 180 days
Contact Now
Detailed Product Description
Color: Black Payload: 200kg
Table's Weight: 200kg Operation Mode: Position, Swing, Simulation, Pre-set Wave Spectrum Etc.
Ambient Temperature: 10℃~40℃ Translational Accuracy: ≤±0.5mm

6 Degree of Freedom Swing Test Table



Description:



6 DOF swing test table is able to provide position analog, sine wave analog, single DOF movement, multiple DOF complex movement according to user's setting within certain range, achieve road spectrum wave process, random wave reproduction, road spectrum, wave spectrum, aviation spectrum reproduction etc. functions.





Technical specification:



Payload capability: 200Kg
Installation dimension of measured device: φ400mm×400mm
Table's weight: About 300Kg
Table surface dimension: Ø1000mm
Table surface flatness: 0.01mm
Table surface beating: 0.02mm
Movement range: Pitch rotation:±30°;Heave sway:±0.3m;
Roll rotation:±30°;Surge sway:±0.3m;
Yaw rotation:±30°;Vertical sway:±0.2m
Operation mode Position, swing, simulation, pre-set wave spectrum etc.
Electrical control cabinet: None(Integrated with table)
Computer system: Industrial control computer, Windows ineterface, RS422, Ethernet (≥100Mbps)
Safety precaution: Real-time display system status and safety protection status;Provide fault tolerance check for command in order to prevent mis-operation.
Ambient temperature: 10℃~40℃
Rotational DOF accuracy: ≤±3′
Translational accuracy: ≤±0.5mm
Rate range: Pitch rotation:±20°;Heave sway:±0.3m;
Roll rotation:±20°;Surge sway:±0.3m;
Yaw rotation:±20°;Vertical sway:±0.3m
Maximum acceleration: Pitch rotation:±200°/s2;Heave sway:±1g;
Roll rotation:±200°/s2;Surge sway:±1g;
Yaw rotation:±200°/s2;Vertical sway:±1g
Movement frequency range: 0.01Hz~0.5Hz
Driver mode: AC motor drive slow drive through electric cylinder
