Reliable EO Ir Imaging Systems Long Range Control For All Weather Conditions

Product Details:

Place of Origin:	Wuhan, China
Brand Name:	HEOS
Model Number:	HITV(-d)

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	30 days

Contact Now

Detailed Product Description

Model:	HEOS-300C	Tracking Accuracy Azimuth:	≤0.5mrad
Director Turning Radius:	≤220mm	Director Height:	≤535mm
Director Weight:	≤40kg	Function:	Automatic Target Tracking
Highlight:	eo ir sensor systems , eo system

Reliable EO Ir Imaging Systems Long Range Control For All Weather Conditions

Main functions

Perform observation, surveillance and search for the targets on air and sea targets in all weather conditions in 24h.
Provide manual and automatic scan and search for the target
Provide automatic target tracking
Provide the radar guidance and tracking function
Calculate and send back the target height information
Color, B/W, infrared, thermal imaging multi-channel imaging system
Provide real-time video recording function, display the information on the same screen and record time and date
Provide long range control function

Main technical specification
TV sensor	Camera		HD 3 megapixel CCD
	Lens		20~360mm HD fog penetration
IR sensor	Waveband		8μm~14μm
	Detector		Cooled 320×256 (or 640×480)
	Lens		44/132mm
Operating distance	Discovery distance (Daytime)		≥12KM
	Discovery distance (Night)		≥10KM
	Recognition distance (Daytime)		≥8KM
	Recognition distance (Night)		≥6KM
Tracking accuracy	Azimuth		≤0.5mrad
	Elevation		≤0.5mrad
Servo capability	Speed		50°/s
	Acceleration		100°/s
Operating range	Azimuth		+175°or 360°continuous rotation
	Elevation		-60°~+80° adjustable
Director	Turning radius		≤220mm
	Height		≤535mm
	Weight		≤40kg
Display and control device	Weight		≤50kg
	Complete machine	Power	500W
		Record time	≥1000h
Optional sensor	Laser illuminator		810nm wave length, power ≥15W
	Laser dazzler		532nm wave length, power is adjustable between 0~2W
	Laser range finder		Range is between 140m-10km, accuracy is ±5m
